Mini Mobile Concrete Batching Plant To Maldives
Jan 13, 2020
Product Name: Mini Mobile Concrete Batching Plant
Model: YHZS60
Capacity: 60 m3/h
Destination: Maldives
Delivery Date: December, 2019
Get quotation: If you like to know mobile batching plant price , welcome to contact us by email: feedom@haomei-machinery.com
Abstract: YHZS60 mobile concrete batching plant is the most time efficient and cost-effective mini concrete plant. All the parts are installed on a transport chassis. When it is delivered to the destination, the first installation took 1 day to finish. After that, it only takes 4-5 hours to start working when moving from one place to another.
It Adopt JS1000 twin shaft concrete mixer, bringing better mixing quality. The whole plant is completely erected and tested at the factory prior to shipping.
Specification of Mobile Concrete Batching Plant
Specification | Unit | Value |
Productivity | m3/h | 60 |
Weighing scale Concrete | kg | 3000 |
Weighing scale Cement | kg | 720 |
Weighing Scale Water | kg | 360 |
Weighing Scale Liquid Additive | kg | 36 |
Overall Power | kw | About 85 |
Power Source | V/ HZ | 380/50 |
Discharge Height | m | 3.8 |
Overall Weight | t | 21(cement silo not included) |
Trail speed | km/h | ≤40 |
Specification(LxWxH) During work | m | 17x3.6x8.2 |
During transportation | m | 17.6x2.4x4.35 |
