What Is Hourly Power Consumption of Small Concrete Batch Plant
Dec 02, 2020
Before building a small concrete batch plant, the customers usually consult the power consumption, cost budget and the return on investment of the mixing plant.
The power consumption of the small concrete batching plant is to add the power of the concrete mixer motor, the power of the concrete batching machine, the power of the screw conveyor and the power of the electric control system together. The result will be the hourly power consumption of the complete concrete mixing plant.
There are different models of concrete batching plants and each model has different power consumption. If you have to calculate the power, add up all the motor power of a mixing plant. How many motors is used in a small concrete batch plant?
1. The concrete mixer has three motors, namely mixing motor, hoisting motor and water pump motor. These three motors add up to 25kw to 90kw.
2. The motor for the belt conveyor.
3. The motor installed on the screw conveyor is about 5.5-19kw.
4. The motor for the pump is about 11kw.
5. The motor on the dust collector is about 0.5kw.
6. The motor on the air compressor is about 4kw.
What’s the hourly power consumption of the small concrete plants?
The overall power of YHZS25 small concrete plant is 55 kw.H.
The overall power of YHZS35 mobile concrete plant is 70 kw.H.
The overall power of YHZS60 portable concrete plant is 85 kw.H.
The overall power of YHZS60 mobile concrete mixing plant is 105 kw.h.
Haomei Machinery has many models of small concrete plants other than the mobile concrete batching plant. We also have rich models of stationary concrete plant. Welcome to leave message below to get a quote.
