What Are Features of The Bolted Cement Storage Silo
Oct 14, 2025
In construction, infrastructure, and other engineering fields, cement storage is crucial for ensuring construction efficiency. The bolted cement storage silos, with its flexibility and practicality, is becoming the preferred equipment for many projects.
Core Features of bolted Cement Silos
1. Convenient transportation
Traditional concrete storage silos are large and heavy, placing stringent requirements on road width and bridge load-bearing capacity for transportation. This is particularly challenging in narrow locations like mountainous areas and rural areas.
Bolted cement silos, on the other hand, feature a modular design and can be disassembled into multiple components, including the silo body, support structure, feed port, and discharge system. Each component is compact and lightweight, making it easy to transport using ordinary trucks, navigating complex road conditions and significantly reducing transportation costs and complexity.
2. Flexible Installation
Bolted cement silos eliminate the need for large lifting equipment. Assembly can be completed manually with a small crane, and can be completed by a team of two to three people in one to two days. Whether used for short-term construction sites or for permanent storage on long-term projects, they can be quickly put into operation. Disassembly is also easy, allowing for quick transfer to the next site after a project is completed. This ensures high reuse rates and reduces idle equipment waste.
3. Safe storage
Cement is sensitive to moisture and contamination, so our bolted cement silos feature exceptional sealing. The silo is welded from high-quality steel plates, with joints sealed with sealant. Equipped with a rainproof roof and moisture-proof discharge valve, it effectively isolates rainwater, moisture, and impurities.
Our cement silos are also equipped with a material level monitoring device, which uses sensors to display the remaining cement in real time. This device also prevents cement from agglomerating due to long-term accumulation, ensuring storage quality.
4. Environmentally Friendly Design
Currently, environmental protection requirements for construction projects are becoming increasingly stringent, and our bolted cement silos incorporate environmentally friendly concepts into their design. The silo roof is equipped with a pulse dust removal device, which quickly absorbs dust as cement enters the silo via the screw conveyor, reducing dust pollution.
5. Strong adaptability
Bolted cement silos can store not only cement but also dry powders such as fly ash, mineral powder, and stone powder, making them suitable for a variety of applications, including concrete batching plants and dry mortar production lines.
Storage capacity can be flexibly adjusted to meet specific needs, ranging from a small 20 cubic meter to a large 100 cubic meter. Whether it's a small civil construction project or a large infrastructure project, there's a suitable model.
Specifications
1. Capacity
Capacity is the key parameter that determines storage capacity. The bolted cement storage silo for sale typically have a capacity range of 20-100 cubic meters.
20-30 cubic meters: It is suitable for short-term, low-volume projects such as small construction sites and rural self-built houses. A single silo can store 15-22 tons of cement (calculated at a cement density of 1.3-1.4 tons/cubic meter).
50-80 cubic meters: It is suitable for medium-sized concrete mixing plants and municipal projects, with a single silo storage capacity of 35-112 tons, meeting the needs of multiple teams working simultaneously.
100 cubic meters: For large-scale infrastructure projects (such as highway and bridge construction), a single silo can store up to 130-140 tons, reducing frequent material loading and improving construction efficiency.
2. Silo Size
Diameter: It commonly ranges from 2.5 to 4.5 meters. Smaller diameters reduce site width requirements and are suitable for narrow sites. Larger diameters provide more uniform storage space within the silo, reducing dead corners where cement can accumulate.
Height: When disassembled, the height of a single section typically does not exceed 3 meters (for easy transportation). When assembled, the total height is 5-10 meters. The specific height should be determined based on the site's vertical space and the installation requirements of the feed and discharge equipment.
3. Material and Thickness
The main silo body is typically constructed of Q235B steel plate, a high-strength, wear-resistant material that can withstand long-term storage pressure and outdoor weathering. Steel plate thickness varies depending on volume.
4. Supporting Equipment Specifications
Feed System: Typically equipped with a screw conveyor with a diameter of 160-219mm, with a conveying capacity of 20-50 tons/hour, adjustable based on cement usage.
Dust Removal Equipment: Pulse dust collectors have a filtration area of 3-8 square meters and a filtration efficiency exceeding 99%, effectively controlling dust emissions.
Level Meters: They are available in paddle and ultrasonic types, with a measurement range of 0-10 meters and an accuracy of ±5%, providing real-time feedback on the remaining material in the cement silo.
