This self loading mixer truck can automatically feed, measure, mix and discharge concrete mixture with its self loading design. Equipped with a powerful engine and 4 wheel steering, the operator can drive it to any places where it is need. We also have other types of common concrete mixer truck.
Small volume and quick movement make it suitable for almost all kinds of construction sites.
Flexible discharging ways. It can discharge concrete at 270 degrees, which is very convenient in narrow and small construction sites.
Different capacities are available. 1.2 m3 , 1.8m3, 2.0m3, 3.5 m3 and 4.0 m3.
Haomei construction equipment has been exported to over 100 countries such as Indonesia, Philippines, Nigeria, America, Columbia,etc. We know your need better if you are from these countries.
Global service system. The worldwide service parts network provides fast, efficient and professional round-the-clock services anytime and anywhere, in order to win the global customer satisfaction and strive to exceed your expectation.
Drum capacity | 1.8 m3 | 3.0m3 | 5.0 m3 | 5.5m3 |
Concrete output | 1.2 m3 | 2.0m3 | 3.5 m3 | 4 m3 |
Loading rate | 76% | |||
Rotary drum | Articuated steering | Discharge mouth height1.8 meter. Lever return 290° | ||
Metering | Electronic weighing system(optional) | |||
Production capacity | 4batches in 1 hour; 5 m3 per hour | 4 batches in 1 hour; 10 m3 per hour | 4 batches in 1 hour; 14 m3 per hour | 4 batches in 1 hour; 16 m3 per hour |
Engine | Yunnei4102,diesel, water cooling, 4 cylinders, 2200 revolutions per minute, rated power 60 kw | Yuchai,diesel, water cooling, 4 cylinders, 2200 revolutions per minute, rated power 78 kw | Yunnei4102,diesel, water cooling, 4 cylinders, 2200 revolutions per minute, rated power 85 kw | Yuchai,diesel, water cooling, 4 cylinders, 2200 revolutions per minute, rated power 92 kw |
Transmission way | Full hydraulic drive, 4 wheel drive and 2 turns | |||
Climbing ability | 30% | 16.7% | 30% | 30% |
Speed range | Low speed 0-25 km/h, high speed 0-45 km/h | Low speed 0-7.2 km/h, high speed 0-25 km/h | Low speed 0-8 km/h, high speed 0- 40 km/h | Low speed 0-25 km/h, high speed 0- 45 km/h |
CAB | Ultra wide deluxe cab, rops type | |||
Hydraulic systems | Open feed, two gear pump participate in action | |||
Joystick | A four-way hydraulic pilot with an electric control button controls the bucket | |||
Bucket | 300L, hydraulic gate | 550L, hydraulic gate | 650L, hydraulic gate | |
Chute | Equipped with two removable shaft pins to increase the discharge length | |||
Water supply system | Self-priming hydraulic pump/electronic water flow monitor/high pressure washer(optional) | |||
Brake | Inner wheel brake and the emergency brake operate on 4 wheels, enabling the small servo pump on the independent double-return road. | |||
Turn | Hydraulic steering, rear wheel steering | |||
Tyre | 12-16.5 tires | 16/17-20PR 16 tires | 16/70-20 wire tires | |
Power system | 24 V | |||
Oil tank/water tank | 2*210l water tank. Diesel tank: 125L. Hydraulic tank: 130L | 2*220l water tank. Diesel tank: 118L. Hydraulic tank: 98L | 2*210l water tank. Diesel tank: 125L. Hydraulic tank: 130L | |
Weight | 4800 kg | 6500 kg | 7600 kg | |
L*w*H | 6030mm*2180mm*2250 mm | 7500 mm*2700 mm*3380 mm | ||
Wheelbase | 1.9M | 1.8 M | 1.9 M | 2.35 M |
We promise one year warranty. There is enough spar parts in stock. Please leave your message on my website, we will arrange shipment within 48 hours.
Go to your site and help you install and debug.
We provide free training for your operator.
If there is something wrong with the self loading concrete mixer machine, you can contact us any time.
If you introduce other users to buy our self loading concrete mixers, we will give you some commission.
