YHZS75 batching plant belongs to a large-sized one among four models with capacity of 75 m3/h. It is is completely mobile and travels as a single load of freight including dust collection, saving you transportation cost. Another large model is YHZS60 mobile RMC plant.
Set up in less than 1 day.
Foundation is not needed in most cases.
Adopt JS1500 concrete mixer for efficient and even mixing performance.
Dynamic display on a computer screen is helpful to operator to adjust the production technology parameters.
Plant is completely erected and tested at the factory prior to shipping.
Specification | Unit | Value |
Productivity | m3/h | 75 |
Weighing scale Concrete | kg | 3750 |
Weighing scale Cement | kg | 900 |
Weighing Scale Water | kg | 450 |
Weighing Scale Liquid Additive | kg | 45 |
Overall Power | kw | About 105 |
Power Source | V/ HZ | 380/50 |
Discharge Height | m | 3.8 |
Overall Weight | t | 25(cement silo not included) |
Trail speed | km/h | ≤40 |
Specification(LxWxH) During work | m | 18.1x3.6x8.2 |
During transportation | m | 18.6x2.4x4.35 |
