It integrates the drum concrete mixer, batching system, weighing system, unloading and fully automatic control system on a trailer unit. YHZM25 mobile concrete mixing plant chooses JZM500 concrete mixer, horizontal cement silo, fully automatic control system, screw conveyor, etc.
The difference between these two series is the chosen concrete mixer. The YHZM series choose drum concrete mixer while the YHZS series concrete plant choose twin shaft concrete mixer. The twin shaft concrete mixer has a relatively higher efficiency and wider applications.
Model | YHZM25 | ||
Capacity | 25m3/h | ||
Concrete mixer | JZM500 | ||
Cycle time | 1.5 minutes | ||
Weighing accuracy | Aggregate | ±2% | |
Cement | ±1% | ||
Water | ±1% | ||
additive | ±1% | ||
Name | Specification | ||
Model | JZM500 drum mixer | ||
Capacity | 0.5m3/batch | ||
Motor power | 4.5kw*2 | ||
Mixing time | 40s | ||
Discharging height | 1300mm; If using concrete transit mixer to collect concrete，we can make a slope with the height of 3000mm to enable it to collect concrete. | ||
Name | Specification | ||
Model | PLD800 | ||
Volume of storage bin | 3.4m3*2pcs | ||
Weighing sensor | 1000kg*3pcs | ||
Cylinder | 100*250*1pcs | ||
Motor power | 4kw*2pcs | ||
Belt conveyor size | 500*3300mm*1 ,600*5880mm*1 | ||
Loading height | 2910mm | ||
Thickness of storage bin steel plate | 3mm | ||
Name | Specification | ||
Qty. | 1 pcs | ||
Size | 11100mm*2000mm*780mm | ||
Tyre model | 1000mm | ||
1. Its market price is very cheap, making it an ideal choice for the customers with limit budget.
2. The accessories of the whole machine are reasonably matched. The appearance of the drum mobile mixing plant is vehicle-mounted.
3. The whole set of equipment can be quickly transported to the construction site in a fully suspended form, assembled on site, and can be constructed without debugging.
4. It is of stable structure, compact structure and flexibility. The production capacity is no less than that of a stationary concrete batching plant.
5. There is no need for a professional transport vehicle to transport it, which can save some transportation costs. It only needs to be towed by a semi-trailer to reach the next destination.
